Piper PA-28R-200 Arrow/PA-28RT-201 Arrow IV With IO-360-C1C,-C1C6 Engine (3-Blade Scimitar)
$18,546.25
Basic Kit:
(PA-28R-200,PA-28R-201,PA-28RT-201 (S/N 28R-7918001 through 28R7918267)(S/N 28R-8018001 and up)
Part Number: PL-60132
(1) Propeller Assembly: B3D36C424/74SA-0 (P4247151-01)
(1) Polished Spinners: D6012-1 (order as: D6012-1A)
(1) Installation Drawing: D60133
(1) Installation Instruction: TR805
(1) Flight Manual Supplement: TR804
(1) Placard: A60139
(1) STC Document Set: SA129CH
(1) Aircraft TCDS Number: 2A13
https://mccauley.txtav.com/-/media/mccauley/files/stc_guide.ashx
PRODUCT ATTRIBUTES:
COUNTRY OF ORIGIN:
ECCN:
WEIGHT:
DIMENSIONS: x x
HARMONIZED CODE:
STC MODIFIER:
Collections: Fees products, Products, STC KITS
Type: MCCAULEY BLACKMAC
Category: 3-BLADE, ARROW, MCCAULEY BLACKMAC, PIPER, PIPER BLACKMAC, STC KITS
